You’ll receive the file to download after the order is complete.Īs always, we recommend using a power supply tester to test your cables once you have made them. Note: For PRIME series the 18pin connector position is switched with the 10pin connectors position. View the example diagram to get an exact (without the correct pinout of course) view of what the diagram looks like. SATA 6.0Gb/s (SATA III, 6.0Gbps) - SATA revision 3.0 doubles the speed of the current 3Gb/s version, reaching transfer speeds of 6Gb/s.Save hours of work with our highly detailed and easy to follow pinout diagram! These diagrams are the same that we use when making our own custom cables for our clients so they are tested and accurate! Everything from which connectors to use and what pins require double wires is just some of the details we included for you making it easy to know which products you’ll need to make your own cables. SATA II uses same encoding as SATA I featuring an actual data transfer rate of 2.4 Gb/s, or 300 MB/s. In practice, some older SATA systems require the peripheral device's speed be manually limited to 150MB/s with the use of a jumper. SATA II devices are required to support the original 1.5Gb/s rate.
A 3Gb/s signalling rate was added to the PHY layer. SATA 3.0Gb/s (SATA II, 3.0Gbps) - second-generation of SATA interfaces. The simplicity of a serial link and the use of LVDS allow to use of longer drive cables. Actual data transfer rate is up to 1.2 Gigabits per second (Gb/s), or 150 megabytes per second (MB/s). SATA/150 (1500Mbps) - first-generation of Serial ATA interfaces, also known as SATA/150, run at 1.5 Gigahertz (GHz). The Serial ATA interface cable consists of four conductors in two differential pairs, plus three ground connections.The cable size may be 30 to 26 AWG with a maximum length of one meter (39.37 inches). The PATA interface is not visible in the diagram. The PATA power connector may be used in instead of the SATA power cable to supply a connection which is more rugged and reliable then the SATA-1 power connection. A Serial ATA Hard drive may also have a third connector for legacy PATA power connections. The Serial ATA (SATA) bus is defined over two separate connectors, one connector for the data lines and one for the power lines.
